| Airframe: |
|
Total Time: 355 Hours
|
|
| |
Garmin G1000 Fully Integrated AvionicsGlass Panel Flight Deck with a Large-Format,
High-Resolution Display SystemConsisting of:
- Dual High Definition Color LCD Displays - GDU 1040 10.4" PrimaryFlight Display (PFD) and 1043 Multi-Function Display (MFD) with XGA (1024 x 768Pixels) Resolution, Wide Viewing Angles, and Clear Sunlight Readability
- Comm 1 - Garmin GIA 63 Communications 16-Watt Transceiver (118.00 to136.992 MHz with 8.33 KHz Channel Increments); WAAS - Upgradeable to C146
- Comm 2 - Garmin GIA 63 Communications 16-Watt Transceiver (118.00 to136.992 MHz with 8.33 KHz Channel Increments); WAAS - Upgradeable to C146
- Nav 1 - Garmin GIA 63 VOR/ILS/LOC Receiver Tuning (108.00 to 117.95 MHz)
- Nav 2 - Garmin GIA 63 VOR/ILS/LOC Receiver Tuning (108.00 to 117.95 MHz)
- Dual GPS - IFR Oceanic - C129A Approved GPS Internal to GIA 63's
- Transponder - GTX 33 Integrated Mode S Transponder with Traffic InformationService (TIS*)
- AHRS 1 - Garmin GRS 77 Integrated Solid-State Attitude Heading andReference System, and GMU 44 Magnetometer
- ADC 1 - GDC 74 Integrated Digital Air Data Computer
- Audio/Marker System - GMA 1347; Audio Control Panel and Intercom Systemwith Associated Aural Tones
- TAWS B - Integrated Class-B Terrain Awareness and Warning System (TAWS)with Worldwide Terrain or Domestic Terrain and Obstacle Database
- EIS Engine Indication Advisories - Function of MFD or PFD in ReversionaryMode
- GEA 71 Engine Airframe Data Concentrator Displayed on MFD
- AFCS - GFC 700 Integrated Automatic Flight Control System (AFCS); FlightDirector (FD) Computations are Performed with the Remote Mounted Autopilotwithin the GSA 80 Servos WX Data Link - GDL 69A
- Hand-Held Microphone (Mounted on end of Armrest between Pilot's andCopilot's Chair)
- Garmin GWX 68 Weather Radar
- WX-500 Stormscope
- Cockpit Speaker
- Static Wicks
- Avionics Master Switch
- Emergency Locator Transmitter (ELT) with Cockpit Switch
- [*TIS is for Domestic Customers only]
[**XM WX Satellite Weather Specifications: AIRMETs, City Forecasts, CountyWarnings, Lightning, METARs (Graphical & Text), NEXRAD Radar (HighResolution), NEXRAD Radar (Summary), Precipitation Type at Surface, SIGMETS,Storm Echo Tops, Storm Cell Attributes, Surface Analysis, TAFs, TFRs, and WindSpeed and Direction at Altitude]
[***XM WX Radio Service Specifications: 68 Commercial free Music Channels, 33News, Sports, Talk and Entertainment Channels, 21 (Audio only) XM InstantTraffic and Weather Channels]
|
| |
- Headliner: Cream Brisa
- Vertical Trim Panels: Granite Wonderfill Fabric
- Horizontal Trim Panels: Acajou Mahogany
- Sidewall and Armrests: Pewter Leather
- Floor Covering: Flint Premier Velour Carpet
- Seat Inserts and Trim: Coldstream and Pewter Leather
- Seat Belts: Grey
- Instrument Panel: Nextel-Suede Dark Anthracite
|
| |
- #1 Color (Overall Top): Matterhorn White
- #2 Color (Stripe): Dark Blue
- #3 Color (Bottom): Grey Metallic
|
| |
- Electro-Thermal Propeller De-Ice System
- 194 Gallons Fuel
- Deice Anti Ice System
- Air Conditioner (Vapor Cycle) includes Five Outlets on Instrument Panel
|
| |
- Manifold Pressure
- Tachometer
- Fuel Flow with Electronic Fuel Flow Transducer
- Individual Cylinder Head and Exhaust Temperature Indicator
- Oil Pressure/Oil Temperature
- Dual Fuel Quantity
|
| |
- Airspeed
- Altitude
- Attitude
- Vertical Speed
- Turn Coordination
- HSI - Horizontal Situation Indicator/Heading
|
| |
- Alternator Load Meter
- Bus Voltmeter
- Magnetic Compass
- Outside Air Temperature Gauge
- Pilot's Control Wheel LCD Digital Chronometer Clock
- Flight Hour Recorder
- Standby Sigma Tek Airspeed Indicator
- Standby Aerosonic Altitude Indicator
- Standby MCI Electronic Attitude Indicator with 45-Minute Battery Backup
|
| |
- Teledyne Continental/Raytheon Special Edition Six Cylinder IO-550-B FuelInjected Engines Rated at 300 Horsepower
- Hartzell Three Blade, Aluminum Alloy, 80" Diameter, Constant SpeedPropellers with Polished Spinner
- Starter
- Gear Driven Alternator
- Dual Pressure Auxiliary Fuel Pump
- Induction Air Filter
- Stainless Steel Muffler with Cabin Heater
- Stainless Steel Muffler with Cabin Heater
- Full Flow Oil Filter
- Non-Congealing Oil Radiator
- Fingertip Opening and Closing of Engine Cowl
Landing Gear and Brakes:
- Tricycle Type with Electro-Mechanical Extension and Retraction System
- Steerable Nose Landing Gear with Shimmy Damper and Beech Oil-Air Strut
- Two-Spot Hydraulic Disc Brakes
- Fully Enclosed Nose and Main Landing Gear
- Auxiliary Landing Gear Extension Control
- Throttle and Flap Controlled, Landing Gear-up Warning Horn, and AnnunciatorLight
- Throttle Controlled, Landing Gear Retract Prevention System
|
| |
- Conventional Dual Column, Three-Axis Control System with Adjustable Pilot's(Left Side) Rudder Pedals
- Adjustable Copilot's (Right Side) Rudder Pedals
- Individual Toe Operated Pilot's and Copilot's Brakes
- Parking Brake with Hand Control
- Electronic Stall Warning Horn
- Adjustable Aileron and Dual Elevator Trim Tabs
- Pedestal Mounted Throttle, Propeller and Mixture Control Levers
- Defroster Control
- Ventilation and Heating Controls
- Electrically Actuated Three Position Fowler Type Flap Controls
- Manual Cowl Flap Control
- Alternate Static Air Source
- Heated Pitot Tube
- Dual Static Airports
|
| |
- 100-Ampere Alternators
- 15.5 Ampere/Hour Battery
- 3.5 Ampere/Hour Battery
- Voltage Regulator
- Over-Voltage Regulator
- External Power Receptacle
- Electrical Circuit Protection
|
| |
- Electroluminescent Sub Panel Lighting
- Instrument Panel Floodlighting in Glareshield
- Landing Gear Position Lights
- Flap Position Indicator Lights
- Trim Tab Position Indicator Lights
- Pilot's and Copilot's White Control Wheel Map Lights
- Adjustable Reading Lights above all Passenger Seats
- Entrance Door and Rear Step Courtesy Lights and Timer
- Outside Air Temperature Gauge Light
- Fuel Tank Selector Light
|
| |
- Landing Light in Nacelle
- Taxi Light on Steerable Nose Landing Gear
- Wing Tip and Tail Navigation Lights
- Anti-Collision Red Flashing Lights on Vertical Tail
- Bottom Mounted White Oscillating Beacon
- Wing Tips and Tail Strobe Lights
|
| |
- Ventilation Blower
- Fresh Air Ventilation System with Eight Individual Outlets
- One-Piece Windshield
- Pilot's Openable Storm Window
- Windshield and Windows with Ultraviolet Protection
- Windows Tinted in Light Gray
- Center Club Seating Window Openable for Ground Ventilation, has PositiveLock to Prevent Opening in Flight, and may be used as Emergency Exit
- Super Soundproofing
- Glove Compartment in Instrument Sub Panel
- Adjustable Front Seat Sun Visors
- Cabin Fire Extinguisher*
- Large Double Doors for Easy Passenger Boarding or Cargo Loading
- Four Coat Hooks
- Four Cup Holders
- Extended Aft Baggage Compartment with Clothes Hanger Bar
- Removable Nylon Hat Shelf in Aft Baggage Area
- Removable Nylon Webbing in Aft Baggage Area
- Capable of Cargo Storage on Aft Cabin Floor
- G & D Tinted Window Inserts
- Matching Black Baggage Restraint Webs and 5th and 6th Seat Support Straps
- *Warning - contains Halon substance which harms public health andenvironment by destroying ozone in the upper atmosphere.
|
| |
- Pilot's and Co-Pilot's Seats with Headrest, Lumbar Support, Shared Armrest,Inertial Reel Shoulder Harness with Matching Lap Belt; Four Position Cam LeverSeat Back Adjustment
- Pilot's Sidewall Storage Pocket
- Club Seating Arrangement:
- Aft Facing 3rd and 4th Seats with Headrests, Lumbar Support, SharedArmrest, Inertia Reel Shoulder Harnesses with Matching Lap Belts, and FourPosition Cam Lever Seat Back Adjustment
- Forward Facing 5th and 6th Seats with Reading Lights, Air Outlets,Headrests, and Inertia Reel Shoulder Harnesses with Matching Lap Belts
- Executive Writing Desk on Left Side with Acajou Mahogany Laminate
- Seats and Sidewalls available in Standard Leather Colors at no AdditionalCost
- Horizontal Trim Panel with Acajou Mahogany Wood or Standard Leather Colorsat no Additional Cost
|
| |
- Exterior High Solids Urethane Paint
- Complete Internal Polyamide Epoxy Corrosion Proofing
- Quick Removable Fuel Tank Caps
- Stainless Steel Cabin Assist Step Raytheon Aircraft Company ManufacturedParts - Five Years (No Hours Limit)
- Systems and Components (Parts not Manufactured by RAC) - Two Years (NoHours Limit)
- Exterior Paint and Interior Finish Items - Two Years (No Hours Limit)
- Garmin Avionics - Two Years (No Hours Limit)
|
| |
