The following items are NEW:
All side windows and windshields
Headliner
Overhead trim (Lights)
Seat upholstery (Front and rear)
Side panels
Carpet
All seat belts
Switches in instrument panel
Vacuum hoses
E.G. T.system
C.H.T. system
Four place intercom wired in.
(No box on floor)
Push to talk switches wired in
ICOM A 200 radio
Outlet for hand held G.P.S.
Firewall padding
Sun visors
Stainless screw kit
Steering rod boots
Brake hoses (at M.L.G)
All tires
Master solenoid
Voltage regulator
Magneto wires from switch to magnetos
Wiring throughout aircraft
Fuel primer lines (cockpit and engine)
Fuel tank vent hoses
Fuel hoses at fuel tank
Engine mounts (Rubber)
Engine baffle (soft)
Engine air filter
Oil pressure lines
(Cockpit and engine compartment)
Engine top end. (Millennium cylinders
with new pistons, piston pins and rings.
160 horsepower upgrade).
Spark plugs
Ignition switch (ACS, no AD on switch)
Door lock (Same key as switch)
Filter on vacuum regulator
Tach (P-I 000 digital)
Power flow exhaust system (23 extra horses)
Slick magnetos and harness
Engine oil pump gears (AD on pump c/w)
The following items were overhauled:
Trim actuator (Rudder)
Rudder pedal bar
Flap handle
Engine primer (Cockpit)
Fuel tank selector valve
Vertical speed indicator
Turn and bank indicator
Artificial horizon
Brake calipers
Nose and main landing gears (New seals)
All main landing gear wheels
All wheel bearings (Repacked)
Aileron bellcranks in wings
Battery box
Carb heat box
Gasalator
Carburetor
Engine baffle (Metal)
Engine mount stripped and painted
Firewall (Engine side), cleaned and painted
Engine major overhaul completed at this time. Tach 000. Case and steel parts certified. Engine reassembled using new bearings, gaskets, internal hardware and safety devices. New bolt PN SL_570_2213 installed. Oil pump AD PCW. Oil cooler flushed. New Millinium cylinder kits installed. New Power Flow exhaust system installed. Rebuilt Carb installed. All new scat tubing installed. Propeller pitched from 50 to 60.

Aircraft chemically stripped and repainted.
The following items were installed new:
windows, upholstery, hat shelf, fuel system hard lines and hoses and strobe system on wings. Vacuum instruments overhauled. New P_I000 digital tach installed with 000 indicated. New ICOM A 200 radio and overhauled KLN 89B GPS installed. New vacuum and static hoses installed. MLG landing gear resealed. New tires and tubes installed. New seals and brake pads installed. Engine mount cleaned and painted. Aircraft weighed and new weight and balance form initiated. All AD's were complied with at this time.

Additional items:
ELT takes D batteries
All AD's completed. Several delated.
Current weight and balance
Aircraft stripped and painted

Engine Specs:
160 HP

Inspection Status:
Annual May 1, 2006
