1968 DEHAVILLAND DHC-6 TWIN OTTER





Price

$2,750,000

Year

1968

Make

DeHavilland

Model

DeHavilland - Turbo

Reg #

N323SJ

Serial #

119

TTAF

28958

Located In

West Palm Beach,MT


Sherman Aircraft Sales
West Palm Beach FL 33412
Alternate Phone: (888) 683-0102


DEHAVILLAND DHC-6 TWIN OTTER

GROUND UP RESTORATION BY ALTENRHEIN AVIATION (SWITZERLAND) WITH NO MONEY SPARED! THIS IS A ONCE IN A LIFETIME OPPORTUNITY TO HAVE A LIKE NEW AIRCRAFT FOR MILLIONS LESS THAN NEW.

REGISTRATION NUMBER: N323SJ

SERIAL NUMBER: 119

AIRFRAME TOTAL TIME: 28,958 HOURS

TOTAL LANDINGS: 50,967 LANDINGS

ENGINES: PRATT & WHITNEY PT6A-34 (PER STC)

BOTH ENGINES & PROPS INSTALLED NEW AUGUST 17, 2012

LEFT ENGINE (S/N PCE-RB0627) 201 HOURS/ 189 CYCLES SINCE NEW

RIGHT ENGINE (S/N PCE-RB0628) 201 HOURS/ 189 CYCLES SINCE NEW

PROPS: HARTZELL PROPELLER HC B3TN 3D

LEFT PROP (S/N BUA 32280) 201 HOURS SINCE NEW

RIGHT PROP (S/N BUA 32279) 201 HOURS SINCE NEW

AVIONICS: (ALL NEW IN 2012)

DUAL GARMIN G600 PFD'S

GARMIN GTN750 WAAS GPS/NAV/COM

GARMIN GTN650 WAAS GPS/NAV/COM

GARMIN GMA 35 AUDIO

GARMIN 796 GPS

2) GARMIN GTX33 TRANSPONDER ADS-B

GARMIN GTS850 TCAS 1 TRAFFIC SYSTEM

GARMIN GWX68 WEATHER RADAR

GARMIN GSR56 IRIDIUM SATELLITE DATALINK

KANNAD 406AF ELT

S-TEC 65 AUTOPILOT

BENDIX KING KR87 DIGITAL ADF

BENDIX KING KN63 DIGITAL DME

MID-CONTINENT EMERGENCY STANDBY ATTITUDE/AIRSPEED/ALTIMETER

INTERIOR:

VIRTUALLY EVERYTHING NEW FROM TOP TO BOTTOM LOOKS LIKE FACTORY NEW!

8 SEATS IN REAR

ZEE SYSTEMS AIR CONDITIONING STC SA 4622SW

NEW VIKING TOILET CUBICLE INSTALLED

THETFORD TOILET IN AFT CABIN ENCLOSED

NEW GLASS HEATED WINDSHIELDS, SB 6/442

NEW ROCKY MOUNTAIN AIR CREW OXYGEN SYSTEM STC

VIKING T5 INDICATION SYSTEM STC

BENZ TORQUE & OIL PRESSURE INDICATION SYSTEM STC

EXTERIOR:

WHITE/DARK BLUE-EXCELLENT CONDITION

NEW GLASS & HEATED WINDSHIELD

RESTORATION/MAINTENANCE:

REPLACED MAIN FRAME AND LH/RH SIDE-FRAMES

NEW LH AND RH WING STRUTS

STRUCTURAL REPAIR OF LH/RH WINGS, REPLACED FRONT SPAR ADAPTERS

NEW LH AND RH LOWER SPAR CAP ANGLE'S INCLUDING SCUFF PLATES

REPLACED FORWARD ALUMINUM WING ADAPTERS WITH STEEL ONES

REPLACED ALL 15 FUEL CELLS WITH NEW

PERFORMED RE-WIRING OF COMPLETE AIRCRAFT

PERFORMED EXTERIOR AND INTERIOR RE-PAINTING OF AIRCRAFT

PERFORMED CORROSION INSPECTION

PERFORMED C12 INSPECTION

ANNUAL INSPECTION- JULY, 2018

REPLACED ALL FLIGHT CONTROL CABLES (RUDDER, ELEVATOR & AILERON)

NEW FORWARD & AFT FUEL TANK MANIFOLDS

NEW AIRFRAME FUEL HOSES

CARRIED OUT SHEET METAL REPAIRS ON FLAPS, AILERONS, ELEVATORS & RUDDERS

CABIN ROOF PANELS AND LOWER FUSELAGE SKIN PARTIALLY REPLACED-8/17/12

NEW CLEVELAND WHEEL AND BRAKE CONVERSION KIT 199-92, STC SA1065GL

ALL AVIONICS AND AUTOPILOT INSTALLED NEW AT RESTORATION

ZIMEX FLAP ROLLER STC

OVERHAULED HYDRAULIC ACCUMULATOR

NEW HYDRAULIC PUMP AND MOTOR

NEW INSTRUMENT PANELS AND SILK SCREENING

OVERHAULED STEERING ACTUATOR

NOSE LANDING GEAR OVERHAUL

MAIN GEAR REPLACED-SUPPLIED BY VIKING AIR-D CHECK

REPLACED LOWER MLG COMPOSITE FAIRINGS

NEW NOSE LANDING GEAR STEERING CABLES

NEW DOOR SEALS

NEW NOSE BAGGAGE DOOR AND SKIN

NEW PILOT, CO-PILOT & AFT BAGGAGE DOOR HINGES

OVERHAULED AIR STAIR DOOR

NEW CABIN FLOOR RAILS, DOUGLASS RAILS, AND FLOORBOARDS

NEW CABIN & COCKPIT DOOR WINDOWS

NEW INBOARD FLAP CONNECTING RODS

NEW ENGINE CONTROL CABLES

BOTH STARTER GENERATORS OVERHAULED

$2,750,000.00- PURCHASE FOR LESS THAN COST OF RESTORATION!

SPECIFICATIONS SUBJECT TO VERIFICATIONS & AVAILABILITY UPON INSPECTION
